EMO 2023 ~ Germany
September 7, 2023
September 18th – 23rd, 2023
at Deutsche Messe, Hannover, Germany
Hall 6 – B90
Exhibits shown
• Technology Introduction of the next generation of linear and rotary encoder
• Product introduction µMate+
High accuracy measurement in a compact form.
The μMATE+ incorporates the advantages of digital and analog gauges while maintaining the feel of conventional lever gauges.
The lever gauge of the DM series enables scanning measurements in various positions. This means that measurements are possible even in areas that are difficult to access or in cramped areas.
The digital display LU20 measurement values can be shown in different display views. The absolute measuring values can be transferred via Bluetooth.
• DS series – Digital gauge with USB interface
Digital gauge with a resolution of 0.1 µm or 0.5 µm for direct connection to the PC or USB hub.
With the measuring lengths from 5 mm to 100 mm, the DS series is perfectly suited for a wide range of measurements during or after the machining process.
• MeasureViewer software for your DS series
Evaluate the measurements values directly on your PC.
o Multiple display possibilities: analog meter, horizontal/vertical bar graph, numerical display
o Available measurement modes: current value / MAX / MIN / P-P
o Tolerance values freely adjustable GO/NG results for current value
o Selectable display range (+/-0.05µm to +/-250mm)
o CSV data output
MG80 series
The MG80 modules offer high speed processing (400µs) of all axis values and calculations. Depending on the communication protocol needed, the matching module can be chosen:
Ethernet (TCP/TP) 1000BASE-TX: MG80-NE
EtherNET/IP: MG80-EI
PROFINET: MG80-PN
EtherCAT: MG80-EC
RS232C: MG80-SC
• Calibration system SET-HD100
Rotary encoder for calibration realizing 0.2 arcsec accuracy.
(Winner of the JSPE technology award 2018)
