The benefits of digital measurement with the feel of an analog gauge.
- Easy-to-read and easy-to-operate 2.7-inch color LCD touch panel.
- Various measurements can be made on 5 different display views.
- µMATE+ can be seamlessly controlled by dedicated mobile apps via Bluetooth® connection.
- ABS values can be easily accessed with minimal configuration.
Specifications
|
Magnescale reserves the right to change product specifications without prior notice. |
|||
| Digital Indicator | |||
| Model | LU20(F) | ||
| Display | 2.7 inch color LCD / Touch Panel | ||
| Input/Output connector | Connection to DS Series : USB Type-A Power supply/Singal interface point : USB Type-C |
||
| Data I/F | Data transmitted by Bluetooth, Main unit controlled by custom apps MicroSD card slot Measuring data can be stored on a commercial MicroSD card |
||
| Main function | Display | Digital numerical display, Analog meter display, Bar graph display, Real-time chart mode, Simple circle measurement | |
| Measuring function | Current, maximum, minimum, peak-to peak, data hold, Display resolution switching (digital, analog), comparator function | ||
| Other | Key lock, display rotation, displayed in inch (oversea model only) | ||
| Power consumption | 6W (when connected to DS Series) | ||
| Power supply | Powered by dedicated lithium-ion rechargeable battery, power supplied by USB Type-C connector (rechargeable) | ||
| Operating temperature | 0 to +40 °C (No condensation) | ||
| Storage temperature | -10 to +60 °C (No condensation) | ||
| External Dimensions | 64 (W) × 40 (D) × 91 (H) mm | ||
| Accessories | USB cable (Type-A ⇔ Type-C 1.2 m), mounting stand, instruction manual, dedicated lithium-ion rechargeable batteries × 2 (replaceable), LCD Screen Protector | ||
Dimensions
Instruction manual
| Product name | Japanese | English |
|---|---|---|
| LU20(F) | – | Download |
Catalog
| LU20(F) | English |  |
|---|
